Aluminum slugs is one kind of competitive products of Haomei Aluminum, which has been welcome by many customers all over the world, for we have adopt high technology on the product process line, which of course ensure the quality. In recent years, we find that the demand of aluminum slugs had been increased, many friends show interest in this product and want to know more information about the aluminum slugs, it is our pleasure to tell my dear friends about the product process of aluminum slugs.
All the aluminum slugs of different shapes are heat-treated, soft - annealed and the surface tumbled or sand blasted. The aluminum slugs are widely used for the manufacturing of aluminum containers or Collapsible Aluminium tubes for cosmetics, pharmaceutical, beverage containers, and many other packaging solutions.
Material | Aluminium Slugs with or without holes |
Alloy | AA1070 |
Purity | 99.70% minimum |
Grain Sizes | Grain 5 |
Hardness | 16 to 19 HB |
Thickness | 3.00 mm. to 10.00 mm |
Diameters | We can supply aluminium slugs of 99.7% Al purity from our aluminium rolling mill. Slugs from Diameter 20 mm to 116 mm can be supplied. The following are the different diameters that can be readily supplied. 20mm, 25 mm, 27mm, 40mm, 45 mm, 50 mm, 54 mm, 63.5 mm, 74 mm, 75 mm, 85 mm, 89 mm, 90 mm and, 116 mm. Slugs to customer's specifications can also be supplied. |
Tolerances | According to norms DIN 59604 |
International Standards | DIN 59604, 1721, ASTM E 112, MIL STD 105 D, EN 570 |
Shape | Flat, Concave, Preform |
Weight | Slugs weight (grs.) is determined by the nominal dimensions of the diameters (mm), thickness (mm) and aluminum density. |
Packing | Corrugated cardboard boxes (25 kg. each), on wooden pallets. |
Finish | Tumble Rolled or Shot Blasted |
>% Si 0.1 |
>% Fe 0.2 |
>% Cu 0.04 |
>% Zn 0.04 |
>% Mg 0.03 |
>% Mn 0.03 |
>% Ti 0.03 |
>% Other 0.01 |
On the one hand, there are many clients ask for aluminum slugs price of our Haomei Aluminum, and we have exported more than 10000 tons of aluminum slugs all over the world, most of the aluminum slugs are applied into packaging, electric, cosmetic, beverage, auto and other industries. On the other hand, there are many friends interested in this kind of product, especially about the aluminum slugs manufacturing process. The whole progress is very complete in our factory and every step are controlled and checked strictly.
Firstly, we received the quotation order from our clients, they may give the specification, drawing to us, what’s more, some customers can give us the sample they need. Then, we produced some sample according to the requirement and send it to customers for testing. After the sample pass the test, the aluminum slugs manufacturing process is starting, we prepared the aluminum coil which meet the grade, the temper, the thickness, then the shape and diameter are set according to the demands of our clients, then the nest step is punching through the punching machine. After punching, the final aluminum slugs are produced. Then we package the products by box or bags and deliver to our customers. During the processing, the thickness and shape are examined by screening machine and manually to ensure there is no bad products.
FOB Reference Price:Get Latest Price
US $2,500-3,500 / Metric Ton | 2 Metric Ton/Metric Tons (Min. Order)
Supply Ability: 1000 Metric Ton/Metric Tons per Month
Port: Qingdao, Shanghai
